Bundy Tube

It covers single-wall, double-wall, copper-brazed steel tubing, zinc-coated steel tubing suitable for general engineering uses, particularly in the automotive, refrigeration, and stove industries for fuel lines, brake lines, oil lines, heating and cooling units, and the like. The tubing is available in either of two types, single strip or double strip. It is delivered in straight length or coil type.

Cold Drawn Precision Single Welded Tubes

Dimension, mm		Tolerance, mm		Mechanical Properties
OD	WT	OD	WT	Tensile Strength, Mpa	Yield Strength, Mpa	Elongation, %
4.00	0.50	±0.08	±0.08	290 min	180 min	25 min
4.76	0.60
4.76	0.65
6.00	0.60
6.00	0.65
8.00	0.60
8.00	0.65
8.00	0.70

Precision Double Copper Welded Steel Tubes

Dimension, mm		Tolerance, mm		Mechanical Properties
OD	WT	OD	WT	Tensile Strength, Mpa	Yield Strength, Mpa	Elongation, %
3.18	0.50	±0.05	±0.05	290 min	180 min	28 min
3.18	0.70
4.00	0.50	±0.08	±0.08			25 min
4.00	0.70
4.76	0.50
4.76	0.70
6.00	0.65
6.00	0.70
8.00	0.70
